Three-in-one Ceramic Rubber Steel Plate Liner

Ceramic rubber composite liner is a hot vulcanization process, the toughened wear-resistant ceramic and rubber vulcanized together to form a rubber-ceramic two-in-one liner, and then use high-strength organic adhesive to bond the liner to the inner shell of the equipment on the steel plate, forming a strong and cushioning force of the anti-wear layer.

Chute And Hopper Wear-resistant Ceramic Liner

Composite wear-resistant ceramic liner is alumina or zirconia wear-resistant ceramics, vulcanized under high-temperature conditions set into the steel groove equipped with special rubber, constituting wear-resistant ceramic composite liner.

Zirconia Toughened Alumina(ZTA) Ceramic Rubber Liner

The advanced vulcanization process will be alumina and zirconia composite ZTA ceramics vulcanized in the rubber, ceramic rubber can also be directly vulcanized on the steel plate, the steel plate with countersunk bolts to increase the firmness between the liner and the equipment, to ensure the reliability of the wear-resistant impact resistance.

Two In One Ceramic Bonding Steel Plates

Wear-resistant ceramic composite steel plate is toughened wear-resistant ceramic with high strength organic adhesive or inorganic adhesive with maximum temperature resistance of 350 ℃ directly bonded to the steel plate groove, steel plate groove with countersunk bolts, the overall liner to form a solid and impact resistant wear layer, a good solution to the problem of large materials conveying equipment in the process of anti-wear. It is suitable for material conveying equipment in high temperature environment as anti-friction lining, and can withstand the impact of large materials.

Wear Resistant Direct Bonding Ceramic Liner

Straight adhesive wear-resistant ceramic liner is made by first pasting wear-resistant ceramic sheets on adhesive paper to form ceramic liners of different sizes. When in use, it is then directly pasted onto the inner wall of the equipment with inorganic high temperature resistant adhesive to form a solid anti-wear layer after curing.

HPA Nano Alumina Ceramic Liner

HPA wear-resistant ceramic lining plate (ceramic rubber composite steel plate) is a hot vulcanization process, the HPA toughened ceramic sheet is vulcanized in the steel plate groove equipped with special rubber. HPA is a kind of supramolecular alumina ceramics, through special technical means to form a supramolecular compact structure of alumina ceramics, wear resistance of more than 99% of alumina ceramics.

Ceramic Polyurethane Composite Liner

Ceramic polyurethane composite liner is a liner formed by vulcanizing anti-abrasive corundum ceramics and steel plate into one through polyurethane. It has strong anti-friction, anti-impact and anti-corrosion properties.

Alumina Ceramic Lining Pipe Elbow

Wear-resistant ceramic pipe lined with wear-resistant ceramics is based on alumina, zirconium oxide as the main raw material, with high abrasion resistance, corrosion resistance and high-temperature resistance performance is good, the project has a low cost, long service life, light weight, transportation and easy to install. and convenient transportation and installation.

Wear Resistance Polyurethane Plate

Polyurethane plate have good properties such as chemical resistance, tensile strength, high elasticity, high pressure load resistance, high abrasion resistance, high shock absorption, tear resistance, radiation resistance, high strength, high load bearing and shock absorption and buffer. High elasticity can be maintained in a wide range of hardness.

Polyurethane Anti-overflow Feeder Skirt Board

The polyurethane anti-spill skirt is an anti-spill and anti-spill self-adjusting conveyor belt skirt system. The Y-shaped anti-overflow skirt consists of a main seal and a secondary seal to form a double seal. It can also be called polyurethane double-sealed skirt panel.

Polyurethane Fiberglass Reinforced Plastic Composite Plate

Polyurethane fiberglass reinforced plastic base composite plate is a composite panel composed of polyurethane and glass fiber reinforced composite plastic. The structure has three layers, namely a wear-resistant polyurethane layer, a color indication layer, and a glass fiber reinforced composite plastic base layer.

Stainless Steel Base Polyurethane Composite Panel

Polyurethane stainless steel base composite panel is made of polyurethane and stainless steel. It has the high mechanical properties of polyurethane, outstanding wear resistance, oil resistance, water resistance, ozone resistance, low temperature resistance, and good insulation. Stainless steel has good It is metallic and can closely fit on the inner wall of the pipe.

Strong Magnet Polyurethane Composite Lining Chute Or Hopper Repair Block

Polyurethane strong magnetic repair block is a combination of polyurethane and strong magnets. It is often used to repair the worn areas of chutes and hopper linings. Polyurethane has excellent wear resistance and mechanical properties, and the hardness can be customized from 50A to 90A. The strong magnet has excellent magnetic properties and can be adsorbed on the chute or hopper. It is easy to install, the replacement process takes a short time, and does not affect the normal operation of the machinery. Polyurethane strong magnetic repair blocks can be customized in shape, color, and size for transporting different materials according to different needs of customers.

Canvas Base Polyurethane Composite Plate

Polyurethane fabric-based wear-resistant plate is a wear-resistant plate made of polyurethane and fabric. It has excellent wear resistance and mechanical properties of polyurethane, and also has the characteristics of good adhesion to fabrics.

Metal Mesh Polyurethane Composite Plate

The wear-resistant liner used in the sliding pipe in the silo in the early days is made of PE material, in use, PE liner is not wear-resistant, the use of short life, the use of the unit is often replaced, affecting the normal incoming and outgoing shipments. And PE material hardness is high, grain in the loading and unloading process, and PE liner contact part, will be a large number of broken, seriously affect the quality of grain. Polyurethane material as a kind of elastomer, with very high wear resistance and resilience buffer performance, polyurethane plate is now widely used in grain silos, grain machinery, etc. as a liner wear plate.

Polyurethane Machine Parts

Polyurethane mechanical parts are mechanical parts made of polyurethane material. Polyurethane mechanical parts have excellent wear resistance and durability. Able to maintain stable performance for a long time in harsh working environments. In addition, polyurethane also has good corrosion resistance and oil resistance, can resist the erosion of chemicals and grease, and prolongs the service life of mechanical parts. Polyurethane mechanical parts are widely used in machinery manufacturing, automobile manufacturing, petrochemical industry and other fields. For example, in automobile manufacturing, polyurethane can be used to make seals, shock absorbers, brake pads and other components: In machinery manufacturing, polyurethane can be used to manufacture bearings, gears, chains and other components.

Belt Conveyor Rubber Skirting

Belt conveyor rubber skirt board, also known as anti-overflow skirt or anti-overflow skirt, is mainly used on belt conveyors to close the material guide trough and the belt to prevent material spillage and dust. The use of this skirt greatly improves the overall safety of the belt conveyor and also makes an important contribution to environmental protection.

Rubber Strong Magnetic Repair Patch

Rubber strong magnetic patch blocks are made of rubber and strong magnets, and are often used to repair worn linings of chutes and hoppers.

Rubber Ceramic Strong Magnetic Repair Patch

Rubber ceramic strong magnetic repair blocks are made of rubber, ceramic and strong magnets, and are often used to repair worn areas of chutes and hopper liners.

Rubber Idler Rollers

Rubber idler rollers are a type of conveyor roller coated in rubber.

Ceramic-lined Rubber Pipes

Ceramic-lined rubber pipes are a type of industrial piping system designed to handle abrasive materials and challenging environments.

Rubber Lining Pipeline For Mine Tailings Treatment

Tailings rubber-lined pipes are a specialized type of pipeline designed to transport slurry.
